Foldable Acoustic Partition Wall

foldable acoustic partition wall is a product that can provide a flexible solution for interior space, not only the most efficient use of space but also the crystallization of innovation and aesthetics. MQ has developed and manufactured foldable acoustic partition wall that are mechanically welded from galvanized steel and have been modified with fittings to achieve the highest acoustic insulation and durability. MQ builds products for customers.

MQ's foldable acoustic partition wall are constantly being improved and we currently use a globally recognized multi-directional rail and pulley system. Whether setting up the sealing system quickly to fix and store the foldable acoustic partition wall, this system can make the process of moving the door panel become very simple and labor-saving.


Steel frame

Compared to the traditional aluminum or steel with wood frame, we use 2mm galvanized steel mechanically welded, more durable.



Innovative sealing strip

We increase the sealing rubber strip to 4 layers. Compared with other products, the contact point increases by about 50%, which greatly improves the sound insulation performance.



Excellent edge closing system

Provide the option of installing protective frame or no frame design, flexible with fixed and replaceable panel, to meet different design schemes.



The construction of screen panel

Screens can be selected in different thicknesses according to the height of the space and the requirements of the client. Single seamless height can be 13 meters, through splicing can be made up to 16 meters.


Screen face plate can have the choice of different material, different combination can have different sound insulation effect. The maximum can reach STC56DB.


Sealing system

Telescopic support at the top and bottom of the screen can not only stabilize the screen, but also tighten the sound insulation seal - providing no less than 25 kg of sealing pressure.

Sealing system

The chimerism between the two panels uses a vertical compression chimerism with a two-way bull nose, which ensures a tight connection between the two panels and effectively prevents sound leakage.


There is a sealing strip made of 4 layers of acoustic tape between the screen and the supporting track, and in 25mm of conventional expansion space.


The telescoping support at the bottom of the top of the screen can pass 180. Rotate the movable handle to open the fixed position simultaneously without repeatedly shaking the handle multiple times.



The foldable acoustic partition wall suspension system

The suspension system is made of high density aluminum alloy, which is fixed and adjusted into a wire by using a barge pin to ensure a smooth and smooth performance as the panel moves on the track.


The barge is made of aluminum alloy, consistent with the material of the track, which ensures a smooth transition and a clean appearance with no change in material, structure or color.


Inside the pulley there are precise horizontal steel ball design bearings, and outside there are polymeric materials or precise steel wheel sets to protect the inner surface of the aluminum alloy rail so that the screen runs smoothly and quietly.

Guangzhou MQ Acousitc Materials Co., Ltd is one of the most experienced manufacturers and suppliers of foldable acoustic partition wall in China. Welcome to buy foldable acoustic partition wall made in China here and get free sample from our factory. All customized products are with high quality and competitive price.
